CARTON INSERTING MACHINE (DIRECT INSERT)

CARTON INSERTING MACHINE (DIRECT INSERT)

Carton Inserting Machine (Contrary Insert)

Product ID: WIB-12

WIB-12 Carton bagging machine is suitable for all kinds of (frozen processing) foods, agricultural products, edible oil, plastic (paper) cups, plastic containers, electronics, stationery, plastics, hardware, screws, beverages, toys ... and other carton bagging.
WAE The constant pursuit of packaging's high efficiency, lower material costs and labor costs makes our customers more competitive.







Features:
  • PLC man-machine interface control.
  • The bagging machine can be used with an open box structure, from the opening, back cover to bagging has always been automated.
  • Use the laminating mechanism to make bags that are in the front of the box for food-grade packaging that is hygienic.
  • The WIB-12 Box Bagging Machine (Positioned) can be set to the length of the film according to customer requirements and made into bags; and a single bundle of film can make bags of various lengths to reduce hoarding.
  • It can be used with various peripheral equipments and is suitable for various packaging methods.
MODEL WIB-12 CARTON INSERTING MACHINE
Machine Size L3170xW2240xH2300mm
Complete carton L(300-600)xW(200-500)xH(300-660)mm
Packaging capacity 10(carton/minute)
Film size 460~840mm
Film length equation CARTON: L+W+150mm= Length of film roll
Power source 1Ø220V(Depend on customer's need)
Air pressure 5kg/cm2
